Description

Easy and intuitive panel
Multi-touch operation similar to smartphone or tablet
Individually adaptable panel operation
Direct integration of timesaving solutions
Flexible finishing and media versatility
Superior security features
Low energy consumption and outstanding eco performance

Functionality

Print and copy speed of up to 30 ppm A4 and 15 ppm A3
Scanning of up 160 ipm in colour and black&white
Fax with Super-G3-Fax option for fast transmission and digital reception, polling, time shift, PC-Fax, receipt to confidential box, receipt to e-mail, FTP, SMB
Standard: Embedded controller with 1.2 GHz

Media

Standard: 1,150 sheets, max. 6,650 sheets
500-sheet universal cassette (A5 lenghtwise - A3, 52-256 g/m²)
500-sheet universal cassette (A5 lenghtwise - SRA3, 52-256 g/m²)
150-sheet bypass (A6 lenghtwise - SRA3; width: 90 to 320 mm, length: 139.7 to 1,200 mm, 52-300 g/m²) for OHP, labels, banner paper, thick paper

Finishing

Inner finisher with corner and 2-point stapling, max. 500 sheets capacity
Punch kit option for inner finisher (2-/4-holes)
50-sheet staple finisher, capacity of max. 3,200 sheets + 100 sheets (via inner tray), stapling for max. 50 sheets
20-sheet booklet finisher, capacity of max. 2,200 + 100 sheets (via inner tray), stapling for max. 50 sheets
Punch kit option for floor-type finisher (2/4-holes)

System Specifications

System memory (standard/max)	2,048 MB/4,096 MB
System hard disk	250 GB (standard)
Interface	10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0 Wi-Fi 802.11b/g/n (optional)
Network protocols	TCP/IP (IPv4/IPv6); NetBEUI; SMB; LPD; IPP; SNMP; HTTP
Automatic Document Feeder (optional)	Up to 100 originals; A6-A3; 35-163 g/m² RADF or Dualscan ADF available
Printable paper size	A6-SRA3; customised paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight	52-300 g/m²
Paper input capacity (standard/max)	1,150 sheets/6,650 sheets
Paper tray input (standard)	1x 500 sheets; A5-A3; 52-256 g/m² 1x 500 sheets; A5-SRA3; 52-256 g/m²
Paper tray input (optional)	1x 500 sheets; A5-A3; 52-256 g/m² 1x 500 sheets; A5-A3; 52-256 g/m² 1x 2,500 sheets; A4; 52-256 g/m²
Large capacity tray (optional)	1x 3,000 sheets; A4; 52-256 g/m²
Manual bypass	150 sheets; A6-SRA3; custom sizes; banner; 60-300 g/m²
Automatic duplexing	A5-SRA3; 52-256 g/m²
Finishing modes (optional)	Offset; group; sort; staple; punch; half-fold; letter-fold; booklet
Output capacity (standard)	Max. 250 sheets
Output capacity (optional)	Max. 3,300 sheets
Stapling	Max. 50 sheets or 48 sheets + 2 cover sheets (up to 209 g/m²)
Stapling output capacity	Max. 1,000 sheets
Letter fold	Max. 3 sheets
Letter fold capacity	Max. 30 sheets; unlimited (without tray)
Booklet	Max. 20 sheets or 19 sheets + 1 cover sheet (up to 209 g/m²)
Booklet output capacity	Max.: 100 sheets; unlimited (without tray)
Copy/print volume (monthly)	Rec.: 10,000 pages Max.¹: 150,000 pages
Toner lifetime	Up to 24,000 pages
Imaging unit lifetime	Up to 150,000/600,000 pages (drum/developer)
Power consumption	220-240 V / 50/60 Hz; Less than 1.58 kW (system)
System dimension (WxDxH)	615 x 725 x 779 mm (without options)
System weight	Approx. 76.5 kg (without options)

Printer Specifications

Print resolution	1,800 x 600 dpi; 1,200 x 1,200 dpi
Page description language	PCL 6 (XL 3.0); PCL 5; PostScript 3 (CPSI 3016); XPS
Operating systems	Windows VISTA (32/64); Windows 7 (32/64); Windows 8/8.1 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Macintosh OS X 10.7 or later; Unix; Linux; Citrix
Printer fonts	80 PCL Latin; 137 PostScript 3 Emulation Latin
Print functions	Direct print of PCL/PS/TIFF/XPS; PDF (v1.7); encrypted PDF files and OOXML (DOCX/XLSX/PPTX); mixmedia and mixplex; "Easy Set” job programming; overlay; watermark; copy protection; carbon copy print
Mobile printing	AirPrint (iOS); Mopria (Android); ineoPRINT (iOS/Android/Windows 10 Mobile); Mobile Authentication and Pairing (iOS/Android) optional: Google Cloud Print; WiFi Direct

Scanner Specifications

Scan speed (mono/colour)	Up to 160 ipm (with optional document feeder)
Scan resolution	Max.: 600 x 600 dpi
Scan modes	Scan-to-eMail (Scan-to-Me); Scan-to-SMB (Scan-to-Home); Scan-to-FTP; Scan-to-Box; Scan-to-USB; Scan-to-WebDAV; Scan-to-DPWS; Scan-to-URL; TWAIN scan
File formats	JPEG; TIFF; PDF; compact PDF; encrypted PDF; XPS; compact XPS; PPTX Optional: searchable PDF; PDF/A 1a and 1b; searchable DOCX/PPTX/XLSX
Scan destinations	2,100 (single + group); LDAP support
Scan functions	Annotation (text/time/date) for PDF; up to 400 job programs; real-time scan preview

User Box Specifications

Storable documents	Up to 3,000 documents or 10,000 pages
Type of user boxes	Public Personal (with password or authentication) Group (with authentication)
Type of system boxes	Secure print Encrypted PDF print Fax receipt Fax polling
User box functions	Reprint; combination Download Sending (e-mail/FTP/SMB and Fax) Copy box to box

Copier Specifications

Imaging technology	Laser
Toner technology	HD polymerised toner
Copy/print speed A4 (mono)	Up to 30 ppm
Copy/print speed A3 (mono)	Up to 15 ppm
Autoduplex speed A4 (mono)	Up to 30 ppm
1st copy out time A4 (mono)	5.4 sec.
Warm-up time	Approx. 20 sec.²
Copy resolution	600 x 600 dpi
Gradation	256 gradations
Multicopy	1-9,999
Original format	A5-A3; custom sizes
Magnification	25-400% in 0.1% steps; auto-zooming
Copy functions	Chapter; cover and page insertion; proof copy (print and screen); adjustment test print; digital art functions; job setting memory; poster mode; image repeat; overlay (optional); stamping; copy protection

Fax Specifications

Fax standard	Super G3 (optional)
Fax transmission	Analogue; i-Fax; Colour i-Fax; IP-Fax
Fax resolution	Up to 600 x 600 dpi (ultra-fine)
Fax compression	MH; MR; MMR; JBIG
Fax modem	Up to 33.6 Kbps
Fax destinations	2,100 (single + group)
Fax functions	Polling; time shift; PC-Fax; receipt to confidential box; Receipt to e-mail/FTP/SMB; up to 400 job programs
